CASE Construction 1816, 1816B, 1816C Uni-Loader Service Manual 8-41040 English
Brand: CASE Construction Equipment
Product Range: Uni-Loader
Publication Type: Service Manual
Equipment Model: 1816, 1816B, 1816C Uni-Loader
Serial Number: -
Publication Number: 8-41040
Issued: Printed in U.S.A. March 1982
Language: English
Pages: 598
File Format: PDF Document
Additional Information: This manual encompasses engine maintenance and repair.
Introduction
This service manual has been prepared with the latest service information available. Troubleshooting, removal, disassembly, inspection and installation procedures, and complete specifications and tightening references can be found in most sections. Some sections have drawings but no written procedure because the job is so easily done. This service manual is one of the most important tools available to the service technician.
If the service manual is for more than one machine or different models of components (planetary axles, gearboxes, control valves, etc.) the procedures have the steps necessary to service each model.
Table of Contents
1. GENERAL
Safety Rules, Service Manual Introduction, and Torque Specifications
Maintenance and Lubrication
Engine Specifications - 1816C
2. ENGINES
Troubleshooting a Hard Starting Engine and D61880 Starter (Square Housing) - 1816 and 1816B
Engine Troubleshooting
Engine Removal and Installation - 1816 and 1816B and Drive Belts - 1816
Engine Removal Installation, 1816C
Tecumseh Engines Mechanic's Handbook - 1816 and 1816B
Onan Engine - 1816C
Engine Accessories
3. FUEL SYSTEM
Engine Controls, Fuel Lines, Fuel Filter, Electric Fuel Pump
Carburetor - 1816C
4. ELECTRICAL
Electrical System Troubleshooting
Wiring Diagrams
Gauges
Battery
Starter
NOTE: Also see the following sections:
Starter - 1816 and 1816B
Alternator - 1816, 1816B
Alternator - 1816C
Spark Ignition System - 1816, 1816B
Spark Ignition System - 1816C
6. POWER TRAIN
Hydrostatic Troubleshooting, Testing, and Adjustment for Machines with Vickers Piston Pumps
Hydrostatic Troubleshooting, Testing, and Adjustment for Machines with Sundstrand Pisfon Pumps
Hydrostatic System Diagrams and Operation for Machines with Vickers Piston Pumps
Hydrostatic System Diagrams and Operation for Machines with Sundstrand Piston Pumps
Vickers Piston Pump
Sundstrand Piston Pump
Hydrostatic Motor
Hydrostatic Controls for Machines with Vickers Piston Pumps
Hydrostatic Controls for Machines with Sunstrand Piston Pumps
Centrifugal Clutch - 1816
Electric Clutch - 1816
Belt Clutch
Drive Chains, Drive Axles, and Hubs
Wheels and Tires
7. BRAKES
Parking Brake
8. HYDRAULICS
Hydraulic Diagrams, Maintenance, and Troubleshooting
Cleaning the Hydraulic System
Equipment Pump
Equipment Control Valve
Auxiliary Control Valve
Cylinders
9. MOUNTED EQUIPMENT/CHASSIS
Loader
Pallet Fork, Manure Fork, and Grapple
ROPS
Decals and Painting
Noise Control
